Product Description

Product Overview

The Lyon Pre-Engineered Pallet Rack Starter with Wire Decking provides heavy-duty industrial storage for palletized inventory in warehouses, distribution centers, manufacturing facilities, and material-handling operations.

Measuring 120”W x 42”D x 144”H, this 10-foot-wide, 12-foot-high starter system features three adjustable storage levels with wire decking.

The starter configuration includes two welded upright assemblies, two beams per level, and wire decking panels. Beam levels can be adjusted in 2-inch vertical increments to accommodate changing storage requirements.

Designed for forklift-loaded palletized materials, Lyon’s teardrop pallet rack combines heavy-duty construction with an expandable design that allows compatible add-on sections to extend the storage system.

Key Features

  • Complete pre-engineered Starter unit
  • 120” / 10 ft. width
  • 42” depth
  • 144” / 12 ft. height
  • 3 storage levels
  • 6,140 lb. capacity per level
  • Wire decking included
  • Two uprights
  • Two beams per level
  • Adjustable on 2” vertical centers
  • Teardrop-style rack system
  • Designed for forklift-loaded pallets
  • Expandable with compatible Lyon Add-On units
  • Lake Green uprights
  • Safety Orange beams
  • Painted steel construction

Specifications

  • Manufacturer: Lyon
  • SKU: 97SWD120042144
  • Type: Pre-Engineered Pallet Rack Starter
  • Width: 120 in.
  • Depth: 42 in.
  • Height: 144 in.
  • Levels: 3
  • Decking: Wire Decking
  • Capacity Per Level: 6,140 lb.
  • Weight: 589.8 lb.
  • Material: Painted Steel
  • Configuration: Starter
  • Upright Color: Lake Green
  • Beam Color: Safety Orange
